Specification：Details
Body Dimensions：Length: 3.6m, Width: 1.8m, Height: 2.35m
Lifting Height：2-section: 3m (Door frame width: 18#), Door frame origin: Shandong Laigang B-series
Load Center Distance：500mm
Door Frame Width (Full Outer) Double door frame: 800mm, Triple door frame: 800mm
Door Frame Material 20MnSiV
Curb Weight：Standard: 5.8T, Triple door frame: 6.2-6.3T
Engine Brand (China II)：Quanchai 4102 Turbo: 81kW, Yunnei 4102 Turbo: 76kW (or optional Huadong 4102 Turbo: 76kW, discount ¥2000)
Engine Power：Quanchai: 81kW, Yunnei: 76kW, Huadong: 76kW
Transmission：Gearbox (OEM by renowned manufacturer, independently developed)
Full-time 4WD：High/low speed, forward/reverse dual push rod
Speed：Continuously variable: 27-28km/h
Low-speed High Torque：Superior off-road performance
Transmission Type：Continuously variable, fully mechanical gear drive (non-traditional cross-axle)
Axles：Front: Large wheel side reduction axle, Rear: 80° steering angle, enabling in-place turning (ideal for tight spaces, independently developed)
Tires：Front: Semi-solid 1670-20, diameter 1030x360mm (semi-solid off-road tread), Rear: Semi-solid 8.25-16, diameter 825x190mm (semi-solid off-road tread, Chaoyang brand)
Tire Pressure：6MPa
Climbing Angle：Unloaded: 35°, Loaded: 25°
Ground Clearance：Door frame: 250mm, Chassis: 320mm
Counterweight：Solid cast iron
Front/Rear Tilt Angle 12°
Minimum Turning Radius：Front wheel: 0.25m, Rear wheel: 2.75m
Wheelbase：2150mm
Notes：Full-time 4WD, center differential (unlocked), suitable for basements, rentals, muddy/snowy roads, slopes, etc.
Braking System：Front wheel braking
Ex-factory Price：Excluding tax and shipping
