verall Length：3.6m
Overall Width：1.8m
Overall Height：2.35m
Lifting Height：2 sections, 3m (gate frame width 18#)
Load Center Distance：500mm
Gate Frame Width (Fully Extended)：Double gate frame width: 800mm, Triple gate frame width: 800mm
Gate Frame Material20MnSi
Vehicle Self-Weight：Standard: 5.8T, 3-section gate frame: 6.2-6.3T
Engine Brand (China IV)：Full Chai 4C6 Turbocharged 81kw, Yunnei 4102 Turbocharged 81kw
Engine Power：Full Chai 81kw, Yunnei 81kw
Transmission：Gearbox (famous brand manufacturer, self-developed)
Full-time 4WD：High and low speed, forward and reverse double push rod
CVT：Stepless speed change, 27-28km/h
Speed：Low speed, high torque, superior off-road performance
Drive Mode: CVT：Full mechanical gear drive (non-traditional spider gear)
Front Axle(Front axle) Large wheel reduction bridge
Rear Axle(Rear axle) Steering angle 80°, capable of in-place steering, more suitable for narrow spaces
Front Tires：Chaoyang half-solid: 1670-20, diameter: 1030*360mm (half-solid off-road pattern)
Rear TiresChaoyang half-solid: 8.25-16, diameter: 825*190mm (half-solid off-road pattern)
Tire Pressure：6 MPa
Climbing Angle：No load: 35°, loaded: 25°
Ground Clearance：Gate frame: 250mm, vehicle chassis: 320mm
Counterweight：Pure solid cast iron counterweight
Forward/Backward Tilt Angle：12°
Minimum Turning Radius：Front wheel: 0.25m, rear wheel: 2.75m
Wheelbase:2150mm
Full-time 4WD Central Differential LockSuitable for basements, rentals, and other uses; suitable for muddy, snowy, and steep road conditions
Braking Mode:Front and rear four-wheel brakes
Ex-factory Price:Excluding tax
